Forward

Reverse

Bandwidth

MHz

47/87~750/862

5~30/65

Technology

Power-Double or GaAs

Push-Pull

Flatness

dB

±0.75

±0.75

RF Return Loss

dB

≥16

≥15

AC Pass through Current

A

10

AC Hum

dB

≥65

≥65

DC Current（24V）

A

1.1

0.2

dB

-20±0.5

-20±0.5

Recommended Input Level

dBuV

72

Full Gain (min)

dBuV

Main output 35

20/25

1) Forward Gain is tested under the amplifier be adjusted correctly

2) Reverse Gain do not include the loss of reverse mixer, and Gain can be changed by different reverse amplifier module.

Bridger output > 40

Output level

dBuV

>112

9dB tilt, 42ch, EN50083, CTB,CSO≤-60dB

Slope

dB

Noise Figure

dB

≤8（0dB Banlance）

≤8（0dB Banlance）

Delay

ns

≤10

5~30≤30

5~65≤20

Surge Protection Voltage

KV

5

Distortion

59  PAL

3  PAL CW

C/CTB

C/XM

C/CSO

dB

dB

dB

≥78

≥75

≥75

≥88

≥80

≥82

Under the recommended RF input level and amplifier gain

Input Voltage

V

AC 50Hz  40~90

Output Voltage

V

DC   +24V

Output DC Current

A

+24V：1.5A  Max,

Work Temperature

℃
